Structure and function
1-12 3HDA000057A8519-001 Torch Service Center - TSC 2013
Assembly instructions
1.5.1 Torch cleaner TC 2013
The TC 2013 torch cleaner is used to clean the gas nozzle which is contaminated with weld spatter
during the welding process. Subsequent spraying of the gas nozzle with a release agent prevents
early contamination of the gas nozzle.
1.5.2 Wire cutter
The write cutter can be used to shorten the welding wire to a particular wire length. It is an add-
on module for the TC 2013 torch cleaner and is also actuated from the latter.
1.5.3 TCP gauging (BullsEye
®
)
TCP measurement is used to measure and adjust the robot tool center point (TCP) It is available
as an add-on module for the TC 2013 or a standalone version (with stand).
A detailed description can be found in Chapter 2 Torch
cleaner TC 2013.
A detailed description can be found in Chapter 3 Wire
cutter.
A detailed description can be found in Chapter 4 TCP
gauging (BullsEye
®
).
