Transport and storage
1-10 3HDA000057A8519-001 Torch Service Center - TSC 2013
Assembly instructions
1.4.3 Damage in transport
If the TSC 2013 or separately ordered assemblies have been damaged in transport, the transport
company must be informed immediately for an expert assessment and a concealed damage claim
must be made.
1.4.4 Storage
The following should be observed in prolonged storage of the TSC 2013:
• storage as far as possible in the original packaging (carton or wooden pallet).
• Lubricate all bare steel parts lightly with commercial, silicone-free corrosion protection oil.
• Seal compressed air connections/plug connectors with protective caps.
• Protect stored parts against moisture.
1.4.5 Packaging/disposal
The transport packaging made available by ABB is used as packaging for the storage of system
components. Disposal takes place only in accordance with contractual agreements entered into.
Table 1-1 Transport weight and packaging
Pos. Qty
[units]
Components Transport
weight [kg]
Packaging
1 1 TSC 2013 - complete 35 Carton
8 TSC 2013 - complete approx. 350 Pallet with wooden crate
2 1 TC 2013 27 Carton
10 TC 2013 approx. 365 Pallet with wooden crate
3 1 Wire cutter 1.5 Carton
10 Wire cutter approx. 17 Carton
4 1 TCP gauging (Bulls Eye) 1.5 Carton
10 TCP gauging (Bulls Eye) approx. 17 Carton
5 1 TCP gauging with stand 10 Carton
10 TCP gauging with stand approx. 180 Pallet with wooden crate
