Spare and wearing parts for TC 2013
Torch cleaner TC 2013 3HDA000057A8519-001 2-29
Assembly instructions
Pos. Qty Name ABB Article No Spare part Wearing
part
1 1 Spray head TC 2013 3HDA000000A9271 x
2 1 Motor pack for milling cutter 3HDA000000A9277 x
3 1 Clamping unit TC 2013 3HDA000057A6670 x
4 1 V-block TC 2013 0.743.800.040 x
5 1 spacer plate
torch-dependent replacement part
Gas nozzle Ø 16 mm
to
Gas nozzle Ø 16 mm
0.746.124.001
to
0.746.124.019
x
6 1 Spray nozzle screen 3HDA000057A4597 x
7 1 Milling cutter
(torch-dependent wearing part) torch-dependent x
8 1 Throttle hollow screw
G1/8” - Type C
Article No 304005-3
ITV GmbH
3HDA000057A5344 x
9 1 Filter regulating valve
LFR-1/8-D-7-MINI
Festo AG & Co. KG
3HDA000057A5023 x
10 1 Oiler
LOE-1/8-D-MINI
Festo AG & Co. KG
3HDA000057A5022 x
11 1 Solenoid valve
VSVA-B-M52-MD-D1-1R5L
Festo AG & Co. KG
3HDA000057A5014 x
12 1 Solenoid valve
MDH-3/2-24DC
Festo AG & Co. KG
3HDA000057A5015 x
13 1 Connecting line
NEBU-M12W5-K-0.5-N-LE3
Festo AG & Co. KG
3HDA000057A5229 x
14 1 Socket
KMC-1-24DC-25-LED
Festo AG & Co. KG
3HDA000057A5040 x
15 1 Sensor holder
SMBZ-8-125/320
Festo AG & Co. KG
3HDA000057A5095 x
16 1 Sensor
SME-8M-DS-24V-K-2.5-OE
Festo AG & Co. KG
3HDA000057A5094 x
17 1 Sensor
CBN10-F46-E2
Pepperl+Fuchs GmbH
3HDA000057A5153 x
18 1 Screw-in silencer
"Legris" G1/4 - 0670 00 13
Parker Hannifin GmbH
3HDA000057A5027 x
