VortexMaster FSV430, FSV450 SwirlMaster FSS430, FSS450 | CI/FSV/FSS/430/450-EN Rev. G 49
Operating mode /
(order code)
Designation Additional parameters required Parameter setting
Gas Std/Norm Vol. /
NG2
Standard volume flow
(for gaseous measuring media)
Operating pressure
3) 5)
Via analog input:
Input/Output / Field Input / Analog In Value ->
Pressure
Via HART input:
Input/Output / Field Input / HART In Value ->
Pressure
Default setting for the pressure value:
Device Setup / Plant/Customized /
Compensation Setting -> Preset
Pressure(abs)
Operating temperature
3) 5)
With internal temperature sensor.
No information required, the measured value
from the temperature sensor is used.
Via analog input:
Input/Output / Field Input / Analog In Value ->
Temperature
Via HART input:
Input/Output / Field Input / HART In Value ->
Temperature
Default setting for the temperature value:
Device Setup / Plant/Customized /
Compensation Setting -> Preset Int.Temp
Compression factor in the standard
condition
(AGA / SGERG only)
Adjustment via DTM/EDD
7)
Compression factor in the operating
condition
Adjustment via DTM/EDD
7)
Gas Mass (Density
under reference
conditions) / NG3
Mass flow rate, calculated with
the density under reference
conditions, pressure and
temperature
(for gaseous measuring media)
Reference pressure and reference
temperature in the normal condition
Device Setup / Plant/Customized / Gas Ref.
Conditions
Via analog input:
(For selection, see operating mode Gas
Std/Norm Vol. / NG2)
Via HART input:
(For selection, see operating mode Gas
Std/Norm Vol. / NG2)
Density under reference conditions Device Setup / Plant/Customized / Gas Ref.
Conditions, as a selection for "Ref. Density"
Gas Mass (actual
density) / NG3
Mass flow rate, calculated using
the current density in the
operating condition.
(gaseous measuring media)
Operating density
2) 3)
Via analog input:
Input/Output / Field Input / Analog In Value ->
Density
Via HART input:
Input/Output / Field Input / HART In Value ->
Density
Default setting for the density:
Device Setup / Plant/Customized /
Compensation Setting -> Preset Density
2) The highest priority of the device is to record the density via the analog input, as long as the analog input is activated as a density input. If the analog input is not
available as a density input, the system attempts to record the density via the HART input. If both the analog input and the HART input are deactivated as a density
input, the system uses the default density value.
3) The connection via the analog input or HART input is described in the chapter titled "Electrical connections" on page 29.
5) The highest priority of the device is to record the temperature via the analog input, as long as the analog input is activated as a temperature input. If the analog input is
not available as a temperature input, the system attempts to record the temperature via the HART input. If both the analog input and the HART input are deactivated
as a temperature input, the system uses the default density value.
7) If for the menu item Device Setup / Plant/Customized -> Gas Std. Mode the selection is set to "Gas linear.", the compression factor is reset to 1.0. See also the
chapter titled "Special operating modes" in the operating instruction.
