ABB VUCG.N - Type VUCG.E and VUCG.N with Tap Selector III and with Tie-In Resistor Switch

1ZSC000562-AAX en, Rev. 1 | Technical guide VUC 35
Type VUCG.E and VUCG.N with tap selector III and with tie-in resistor switch
Fig. 51. Dimensions, type VUCG.E and VUCG.N with tap selector III and with tie-in resistor switch.
Model for mounting on
transformer’s active part
Model for cover mounting
C/L Diverter switchC/L Tap selector
Section A - A
Linear switching
Section A - A
Plus/Minus and
Coarse/Fine
switching
