Abbott 3599 - Operating Parameters; EPG Operating Parameters

Table 4. Operang parameters for the EPG
Tonic Range Tonic Steps Burst Range* Burst Steps*
Pulse width 50 - 500 µs 10 µs 50 - 1000 µs 50 µs
Frequency 2 - 200 Hz
200 - 500 Hz
500 - 1200 Hz
2 Hz
10 Hz
20 Hz
— —
Burst rate frequency — — 10 - 60 Hz 10 Hz
Intra-Burst frequency — — 250 - 500 Hz
500 - 1000 Hz
10 Hz
20 Hz
Amplitude 0 - 25.5 mA 0.1 - 1.0 mA 0 - 12.75 mA 0.05 - 0.50 mA
Smulaon output Constant current Constant current
NOTE:
▪
Columns with * represent operang parameters for
BurstDR
™ smulaon programs on EPGs capable of
▪
BurstDR
smulaon mode.
▪
The maximum current depends on the impedance, frequency, and pulse width sengs.
▪
33
