Abbott 3599 - Radio Transmitter and Cables; Radio Transmitter Parameters

Table 6. Bluetooth® Low Energy (LE) wireless technology informaon
Output power (EIRP*) 1 mW (0 dBm) typical, 10 mW (+10 dBm) maximum
Range 2 meters typical
Center frequency 2.44 GHz
Channel 40 logical channels
Bandwidth 2 MHz per channel
Data rate 1 Mbit/s
Data ow Bi-direconal
Protocol Bluetooth LE wireless technology
*EIRP = Equivalent isotropically radiated power
Radio Transmier, Cables, Transducers
The device contains a radio transmier/receiver with the following parameters.
Radio transmier parameters:
▪ Frequency (range): 2.4000 to 2.4835 GHz▪
▪
Bandwidth (-15 dB): 2.398 to 2.4855 GHz
▪
▪ Channel: 40 logical channels using AFH▪
37
