Symbol Descripon
Indicaon of an interval or delay. When an interval or delay is present between two
chambers, the image is modied to include a space or gap.
Sensed atrial to ventricular interval
AV Delay: Paced/Sensed
Pulse amplitude and pulse width
Pulse amplitude/width, right ventricular, le ventricular
Sensivity
Refractory period
Sensing
Therapy delivered
Auto polarity detecon
