Abit AL8 User Manual

2-8 Chapter 2
(3). CMOS Memory Clearing Header
This header uses a jumper cap to clear the CMOS memory.
• Pin 1-2 shorted (default): Normal operation.
• Pin 2-3 shorted: Clear CMOS memory.
WARNING: Turn the power off first (including the +5V standby power) before clearing the CMOS
memory. Failing to do so may cause your system to work abnormally or malfunction.
AL8 Series

Abit AL8 Specifications

General

Brand	Abit
Model	AL8
Category	Motherboard
Language	English
