Abit AL8 - Front Panel Audio Connection Header

2-10 Chapter 2
(5). Front Panel Audio Connection Header
This header provides the connection to audio connector at front panel.
Pin Pin Assignment Pin Pin Assignment
1 MIC2 L 2 AGND
3 MIC2 R 4 AVCC
5 FRO-R 6 MIC2_JD
7 F_IO_SEN
9 FRO-L 10 LINE2_JD
