2-14 Chapter 2
(9). GURU Clock Connection Header
This header is reserved for connecting ABIT’s exclusive GURU Clock.
(10). Internal Audio Connectors
This connector connects to the audio output of internal CD-ROM drive or add-on card.
AL8 Series
