1-2 Chapter 1
• 2x PCI slots
• 1x Floppy port supports up to 2.88MB
• 2x SATA connectors (For model AL8 only)
• 4x SATA connectors
• 1x Ultra DMA 100/66/33 connector
• 2x USB 2.0 headers
• 1x IEEE 1394 header (For model AL8 only)
• 1x FP-Audio header
• 1x CD-IN header
12. Back Panel I/O
• 1x PS/2 Keyboard, 1x PS/2 Mouse
• 1x Serial port, 1x Parallel port
• 1x S/PDIF In connector (For model AL8 only)
• 1x S/PDIF Out connector (For model AL8 only)
• 1x AUDIO1 connector (Surround-Left/Surround-Right, Rear-Left/Rear-Right,
Center/Subwoofer)
• 1x AUDIO2 connector (Mic-In, Line-In, Line-Out)
• 4x USB connectors
• 1x IEEE 1394a connector (For model AL8 only)
• 1x RJ-45 LAN connector
13. Miscellaneous
• ATX form factor (305mm x 245mm)
! Specifications and information contained herein are subject to change without notice.
AL8 Series
