24
|
Charging procedure
4 Check the status indicator of the wallbox.
x If the charging operation has to be enabled
using an RFID card, a blue chase light is
shown dynamically on the status indicator.
5 Hold a valid RFID card in front of the status
indicator.
6 Check the status indicator and acoustic signals
of the wallbox.
x If the RFID card has been read successful-
ly, the wallbox emits a short sound signal
and checks the authentication of the RFID
card.
x After successful authentication, the wall-
box emits two further short sound signals
and activates the charging operation.
x If the authentication is not successful, the
status indicator lights up orange and the
wallbox emits three long sound signals.
NOTE
The authentication of the RFID card is not successful
If the RFID card could not be verified, do one of the following:
x Remove the charging connector from the charging socket of the wallbox and wait until the status
indicator pulsates green again. Then repeat steps 2 to 6.
x Operating the wallbox with a backend: Please contact the issuer of the RFID card.
x Operating the wallbox without backend: Make sure that the RFID card has been registered to the
relevant wallbox. You can find further information in the comprehensive installation manual.
