Control card Indicators
Indicator
Color
Status
Description
Running
indicator
Green
Flashing once every 1s
The receiving card is functioning normally.
Ethernet cable connection is normal, and
video source input is available.
Flashing once every 3s
Ethernet cable connection is abnormal.
Flashing 3 times every 0.5s
Ethernet cable connection is normal, but
no video source input is available.
Flashing once every 0.2s
The receiving card failed to load the
program in the application area and is
now using the backup program.
Flashing 8 times every 0.5s
A redundancy switchover occurred on
the Ethernet port and the loop backup
has taken effect.
Power
indicator
Red
Always on
The power input is normal.
Power cord connection instructions: Please calculate and select the appropriate model of
distribution box or socket according to the maximum power consumption. Please consult
your electrician or distribution cabinet manufacturer for specific selection scheme. The
input voltage of the cabinet is 100-240V/AC. The 3X2.5mm
2
/14awg power cable is used
from the distribution box to the cabinet. Please confirm the input voltage, The number of
cabinets loaded on each power cable will be different upon different voltages and product
models. (Please feel free to contact our after-sales service department if you cannot
confirm).
Data and power wiring schematics are shown below:
4.1 Power Supply Wiring
When the input voltage is 220V, each power cable can carry up to 28 cabinets. When the
input voltage is 110V, each power cable can carry up to 14 cabinets. the cabinets are
connected with power cables of connecting cabinets, and then connect the distribution
box
or socket to the bottom of cabinet with 3 x 2.5mm²/14awg power cables.
