NO. PARAMETER NAME RANGE OF ADUSTMENT DEFAULT
(NOTE 1)
12 TB-13C FUNCTION NONE (01), 0-10 VDC (02), 4-20 mA (03), NONE (01)
SELECT PRESET SPEED #3 (04), INCREASE FREQ (05),
EXTERNAL FAULT (06), REMOTE KEYPAD (07),
DB FAULT (08), ACCEL/DECEL #2 (09)
13 TB-15 OUTPUT (SEE PARAMETER 6 - TB-14 OUTPUT) NONE (01)
14 CONTROL TERMINAL STRIP ONLY (01), TERMINAL STRIP
REMOTE KEYPAD ONLY (02), ONLY (01)
TERMINAL STRIP OR REMOTE KEYPAD (03)
15 SERIAL LINK DISABLE (01), 9600, 8, N, 2
9600, 8, N, 2 WITH TIMER (02), WITH TIMER (02)
9600, 8, N, 2 WITHOUT TIMER (03),
9600, 8, E, 1 WITH TIMER (04),
9600, 8, E, 1 WITHOUT TIMER (05),
9600, 8, O, 1 WITH TIMER (06),
9600, 8, O, 1 WITHOUT TIMER (07)
16 UNITS EDITING TENTHS OF UNITS (01), WHOLE
WHOLE UNITS (02) UNITS (02)
17 ROTATION FORWARD ONLY (01), FORWARD
FORWARD AND REVERSE (02) ONLY (01)
19 ACCELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC
20 DECELERATION TIME 0.1 - 3600.0 SEC 20.0 SEC
21 DC BRAKE TIME 0.0 - 3600.0 SEC 0.0 SEC
22 DC BRAKE VOLTAGE 0.0 - 30.0 % 0.0 %
23 MINIMUM FREQUENCY 0.0 - MAXIMUM FREQUENCY 0.0 Hz
24 MAXIMUM FREQUENCY MINIMUM FREQ - 240.0 Hz (NOTE 2) 60.0 Hz
25 CURRENT LIMIT 30 - 180 % (NOTE 3) 180%
26 MOTOR OVERLOAD 30 - 100 % 100%
PARAMETER MENU (CONT’D)
NOTE 1: Factory defaults are shown for a 60 Hz base frequency. See Parameter 48 for 50 Hz base frequency.
NOTE 2: Maximum setting is 999.9 Hz on drives with High Output Frequency option. Consult the factory.
NOTE 3: If LINE VOLTAGE is set to LOW, maximum setting is 150%.
