NO. PARAMETER NAME RANGE OF ADJUSTMENT
DEFAULT
(NOTE 1)
27 BASE FREQUENCY 25.0 - 500.0 Hz (NOTE 4) 60.0 Hz
28 FIXED BOOST 0.0 - 30.0 % 1.0 %
29 ACCEL BOOST 0.0 - 20.0 % 0.0 %
30 SLIP COMPENSATION 0.0 - 5.0 % 0.0 %
31-37 PRESET SPEEDS 0.0 - MAXIMUM FREQUENCY 0.0 Hz
38 SKIP BANDWIDTH 0.0 - 10.0 Hz 0.0 Hz
39 SPEED SCALING 0.0 - 6500.0 0.0
40 FREQUENCY SCALING 3.0 - 2000.0 Hz 60.0 Hz
41 LOAD SCALING 10 - 200 % 200 %
42 ACCEL / DECEL #2 0.1 - 3600.0 SEC 20.0 SEC
43 SERIAL ADDRESS 1 - 247 1
44 PASSWORD 000 - 999 225
47 CLEAR HISTORY MAINTAIN (01), CLEAR (02) MAINTAIN (01)
48 PROGRAM USER SETTINGS (01), OEM SETTINGS (02), USER
SELECTION RESET OEM (03), RESET 60 (04), SETTINGS (01)
RESET 50 (05), TRANSLATE (06)
50 FAULT HISTORY (VIEW-ONLY) (N/A)
51 SOFTWARE CODE (VIEW-ONLY) (N/A)
52 DC BUS VOLTAGE (VIEW-ONLY) (N/A)
53 MOTOR VOLTAGE (VIEW-ONLY) (N/A)
54 LOAD (VIEW-ONLY) (N/A)
55 0-10 VDC INPUT (VIEW-ONLY) (N/A)
56 4-20 mA INPUT (VIEW-ONLY) (N/A)
57 TB STRIP STATUS (VIEW-ONLY) (N/A)
58 KEYPAD STATUS (VIEW-ONLY) (N/A)
59 TB-30 OUTPUT (VIEW-ONLY) (N/A)
60 TB-31 OUTPUT (VIEW-ONLY) (N/A)
PARAMETER MENU (CONT’D)
NOTE 1: Factory defaults are shown for a 60 Hz base frequency. See Parameter 48 for 50 Hz base frequency.
NOTE 4: Maximum setting is 1300.0 Hz (factory default is 999.9) on drives with High Output Frequency option.
Consult the factory.
To Next Page
