SM01P 28
14 PARAMETER MENU
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
01 LINE VOLTAGE HIGH (01), LOW (02) HIGH (01)
02 CARRIER FREQUENCY 4kHz (01), 6 kHz (02), 8 kHz (03), 10 kHz (04) 6 kHz (02)
03 START METHOD
NORMAL (01), START ON POWER UP (02),
START WITH DC BRAKE (03),
AUTO RESTART WITH DC BRAKE (04),
FLYING RESTART 1 (05),
FLYING RESTART 2 (06),
FLYING RESTART 3 (07)
NORMAL (01)
04 STOP METHOD
COAST (01), COAST WITH DC BRAKE (02),
RAMP (03), RAMP WITH DC BRAKE (04)
COAST (01)
05
STANDARD SPEED
SOURCE
KEYPAD (01), PRESET #1 (02),
0-10 VDC (03), 4-20 mA (04)
KEYPAD (01)
06 RELAY OUTPUT
NONE (01), RUN (02), FAULT (03),
INVERSE FAULT (04), FAULT LOCKOUT (05),
AT SET SPEED (06), ABOVE PRESET #3 (07),
CURRENT LIMIT (08), AUTO SPEED (09),
REVERSE (10)
NONE (01)
10
TB-13A FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #1 (04),
START FORWARD (05),RUN REVERSE (06),
START REVERSE (07),
EXTERNAL FAULT (08),
INVERSE EXT FAULT (09),
AUXILIARY STOP (10),
ACCEL/DECEL #2 (11)
NONE (01)
11
TB-13B FUNCTION
SELECT
NONE (01), 0-10 VDC (02), 4-20 mA (03),
PRESET SPEED #2 (04), DECREASE FREQ (05),
START FORWARD (06), JOG FORWARD (07),
JOG REVERSE (08), EXTERNAL FAULT (09),
INVERSE EXT FAULT (10), AUX. STOP (11),
ACCEL/DECEL #2 (12), REMOTE KEYPAD (13)
NONE (01)
