35 SM01P
05 DECREASE FREQ: Closing TB-13B to TB-11 will decrease the speed setpoint until
the contact is opened. TB-13E must be programmed for INCREASE FREQ.
06 START FORWARD: Sets up the drive for a 3-wire start/stop circuit. Momentarily close
TB-13B to TB-11 to start the drive, and momentarily open TB-1 to TB-11 to stop.
07 JOG FORWARD: Close TB-13B to TB-11 to JOG in the forward direction. The drive
will run at PRESET SPEED #2 (Parameter 32) when in JOG mode.
08 JOG REVERSE: Close TB-13B to TB-11 to JOG in the reverse direction. The drive
will run at PRESET SPEED #2 (Parameter 32) when in JOG mode.
WARNING!
• When operating in JOG mode, the STOP signal and the AUXILIARY STOP
function (see Parameters 10-12) WILL NOT stop the drive. To stop the drive,
remove the JOG command.
• JOG REVERSE will operate the drive in reverse rotation even if ROTATION
DIRECTION (Parameter 17) is set to FORWARD ONLY.
09 EXTERNAL FAULT: Sets TB-13B as a normally closed external fault input. Open
TB-13B to TB-11 to trip the drive.
10 INVERSE EXTERNAL FAULT: Sets TB-13B as a normally open external fault input.
Close TB-13B to TB-11 to trip the drive.
11 AUXILIARY STOP: When TB-13B is opened with respect to TB-11, the drive will
decelerate to a STOP (even if STOP METHOD is set to COAST) at the rate set into
ACCEL/DECEL #2 (Parameter 42).
12 ACCEL/DECEL #2: Selects the acceleration and deceleration time programmed into
Parameter 42 - ACCEL/DECEL #2.
13 REMOTE KEYPAD: When the Remote Keypad option is being used, TB-13B must
be set to this function. Also, TB-13E (Parameter 12) must be set for REMOTE
KEYPAD (21), and CONTROL (Parameter 14) must be set to REMOTE KEYPAD
ONLY (02).
NOTE
If the drive is commanded to JOG while running, the drive will enter JOG mode and
run at PRESET SPEED #2 (Parameter 32). When the JOG command is removed,
the drive will STOP.
P12 TB-13E FUNCTION SELECT
Parameter P12 selects the function of terminal TB-13E. This terminal can be configured
as a digital input (settings 01 to 10) or a digital status output (settings 11 to 20). When
used as an input, closing TB-13E to TB-11 (or opening in the case of settings 07 and 09)
activates the selected function.
When used as an output, P12 can provide the drive's status for monitoring. If the Remote
Keypad option is being used, this parameter must be set to REMOTE KEYPAD (21).
