Accu-Chek Guide User Manual

10
Your New System
1
9. Test Strip Container*
10. Metallic End
Insert this end into meter.
11. Yellow Edge
Touch blood drop or control solution here.
12. Control Solution Bottle*
13. Batteries
14. USB Cable*
Connects the meter to a PC.
*Some items may not be included in the kit.
They are a separate purchase.
(for example) Test Strip
9
10
11
12
14
13
54988_08100918001_EN.indb 10 9/30/16 5:04 PM

Accu-Chek Guide Specifications

General

Measurement Range	10 to 600 mg/dL
Test Time	Less than 4 seconds
Battery Life	Approximately 1000 tests
Connectivity	Bluetooth
Sample Size	0.6 μL
Weight	Approx. 40 g (1.4 oz) with battery
Battery Type	2 x CR2032 lithium coin cells
Display	LCD
Operating Conditions	10-40°C (50-104°F), 10-90% relative humidity
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
