Your New System
1
The Accu‑Chek FastClix Lancing Device
1. Cap
For fingertip testing.
2. Comfort Dial with Depth Selection
Select penetration depth.
3. Penetration Depth Indicator
Points to depth setting.
4. Lever
Advance to a new lancet.
5. Lancet Counter Window
Shows number of available lancets.
6. Release Button
Press to prime and prick.
7. Lancet Drum
Contains 6lancets.
NOTE
Some items may be sold separately.
1
2
7
5
6
4
3
54988_08100918001_EN.indb 11 9/30/16 5:04 PM

Accu-Chek Guide Specifications

General

Measurement Range	10 to 600 mg/dL
Test Time	Less than 4 seconds
Battery Life	Approximately 1000 tests
Connectivity	Bluetooth
Sample Size	0.6 μL
Weight	Approx. 40 g (1.4 oz) with battery
Battery Type	2 x CR2032 lithium coin cells
Display	LCD
Operating Conditions	10-40°C (50-104°F), 10-90% relative humidity
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
