Accu-Chek Guide User Manual

39
Control Tests
4
Select the control solution to test. You will enter
the level later in the test.
4
Remove the bottle cap. Wipe the tip of the bottle
with a tissue. Squeeze the bottle until a tiny drop
forms at the tip.
5
Touch the drop to the yellow
edge of the test strip. Do not
put control solution on top of
the test strip.
Analyzing appears when there
is enough control solution in
the test strip.
6
54988_08100918001_EN.indb 39 9/30/16 5:04 PM

Accu-Chek Guide Specifications

General

Measurement Range	10 to 600 mg/dL
Test Time	Less than 4 seconds
Battery Life	Approximately 1000 tests
Connectivity	Bluetooth
Sample Size	0.6 μL
Weight	Approx. 40 g (1.4 oz) with battery
Battery Type	2 x CR2032 lithium coin cells
Display	LCD
Operating Conditions	10-40°C (50-104°F), 10-90% relative humidity
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
