Accu-Chek Guide User Manual

40
Control Tests
4
Control Result and the control bottle symbol appear.
Press
or to select the control level you tested. If you do not
select a level, the control result is saved without a control level.
Press
.
7
Within range and appear if the control result is within range.
Out of range and
appear if the control result is out of range.
8
or
54988_08100918001_EN.indb 40 9/30/16 5:04 PM

Accu-Chek Guide Specifications

General

Measurement Range	10 to 600 mg/dL
Test Time	Less than 4 seconds
Battery Life	Approximately 1000 tests
Connectivity	Bluetooth
Sample Size	0.6 μL
Weight	Approx. 40 g (1.4 oz) with battery
Battery Type	2 x CR2032 lithium coin cells
Display	LCD
Operating Conditions	10-40°C (50-104°F), 10-90% relative humidity
Storage Conditions	-25°C to +70°C (-13°F to +158°F)
