Accu-Chek Nano User Manual

40
5. Dial to the depth selection
appropriate for the testing site.
Set the lancing device aside
until later in the test.
6. Check the Use By date on the
test strip container. Do not use
test strips past the Use By
date.
7. Insert a test strip into the meter
in the direction of the arrows.
NOTE
We suggest starting at a depth setting of 3 for palm testing. Once you perform a successful test, you may
want to find the lowest depth setting that provides enough blood with the least amount of pain.

Accu-Chek Nano Specifications

General

Display Type	LCD
Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	500 results
Automatic Power Off	Yes
Memory	500 results
Dimensions	69 x 43 x 20 mm
Weight	40 g with batteries
Measuring Range	0.6 - 33.3 mmol/L
Operating Conditions	10 - 90% relative humidity
