Chapter 2: The LC1400T 2-8
Mounting
To mount an LC1400T:
1) Remove the LC1400T cover and screws.
2) Locate, align, mark-out, and drill
4 mounting holes in the wall that
correspond to the mounting holes of the
LC1400T.
3) Using appropriate hardware for the
mounting surface, install the four
anchors.
4) Install the upper screws. Leave about
1/8th inch of each screw exposed.
5) Make any wire accommodations (such
as fishing wires through the back cover
or planning conduit/panduit interface)
that are more easily completed while the
LC1400T is unmounted.
6) Install the last two mounting screws, then
tighten all four mounting screws.
7) Proceed to wiring.
Wiring
The LC1400T uses a 15 VDC plug-in power
supply.
For instructions on wiring to the LC1400T,
refer to the chapter on the component you are
interfacing with.
• Do not connect a plug-in power supply to
a receptacle controlled by a switch.
• All wiring connections must be done in
accordance with NFPA 70.
• Use UL-approved, plenum rated cable.
Important
