Chapter 3: Tags, IDTAD, & TTS3-2
• LC1400 System Tags
• Tag Bar Codes
• Visual Pulse LED
• Attaching LT/WW Tags
• Tag and Band Maintenance
• The IDTAD
• The Tag Test Station
LC1400 System Tags
The LC1400 system uses LC1400 system tags.
The tags have three styles:
• LT (Part #77S018) (Figure 3.1)
» LT-W (Waterproof tag; Part #77S018-W)
• SB (Part #77S016) (Figure 3.2)
• WW (Wander Wearable) (Part #77S017)
(Figure 3.3)
Each style of tag is activated and deactivated
with an IDTAD unit.
The LT/SB tag band (Part #100901) is made
from nylon-mesh-reinforced vinyl (latex-free).
The WW tag band (Part #100917-5), which
includes a snap fastener, is made from silicon.
Each band is designed to resist tearing caused
by pulling or chewing. If a band becomes
frayed or torn, it will need to be replaced.
In long-term applications, a band should be
replaced periodically for cleanliness.
Tags, IDTAD, & TTS
Figure 3.1
LT tag case style
Figure 3.2
SB tag case style
