3-15Chapter 3: Tags, IDTAD, & TTS
IDTAD Specications
Electrical
3.7 VDC 1600 mAh (5.92 Wh) Lithium Ion
battery pack. (DO NOT attempt to repair or
rebuild/replace the cells within).
Component Cell: UL 1642
Test Specification: UL2054:2004 R9.11
Maximum Charging Current: 0.8 A
Nominal Charging Voltage 5.0 V
Battery Shipping Compliance: UN38.3
Charging Cable: USB Type C - charges via
a computer USB port or a 120 VAC to 5
VDC/500 mA Adapter (not included) Note:
using a charger that provides less than the
recommended 500 mA can work but will take
longer than normal to charge.
Mechanical:
Size: approximately 5.50” x 3.00” x 1.25” (with
boot)
Weight: 7 ounces
Environmental:
Operating Temperature: 32º to 120º Fahrenheit
Intended for indoor use only.
Operating characteristics:
Transmit Frequency: 127.0 kHz
Receive Frequency: 418 MHz
Internal Security Tag Transmit Frequency: 418
MHz
Internal Security Tag Receive Frequency: 127–
137 kHz
FCC ID: JM7-HWHY-662015
Canada IC: 2683A-662015
Figure 3.16a
Battery Pack Label Front View
Figure 3.16b
Battery Pack Label Back View
7. Select MBM Display
Press 7. The following will be displayed:
Press 1 or 2 to configure MBM display
1. Display BABY
2. Display PEDS
CURRENT: BABY
"BABY" is the default. If you press 2, “PEDS"
will then be the setting displayed.
Enter>Enter returns you to the menu screen.
