Accutech LC1400 User Manual

Chapter 3: Tags, IDTAD, & TTS3-16
Installing and Removing the
Battery
Installing
1) Connect the new battery plug terminal
to the main board (Black – left, Yellow –
Center, Red – Right) (Figure 3.17a).
2) Replace the IDTAD cover and secure with
the four Phillips-head screws.
3) Replace the battery cover.
4) Charge the new battery/unit for at
least 4 hours before use. (see Charging,
Powering, & Unlocking the IDTAD)
Removing
1) Disconnect and remove the USB cable.
When you disconnect a cable, pull on its
connector or on its pull-tab— not on the
cable itself.
Warning
2) Remove the battery cover.
3) Remove the four Phillips-head screws.
4) Remove the IDTAD back cover.
5) Carefully remove the battery pack from
the compartment.
6) Carefully unplug the battery pack
terminal from the main board connector.
7) Properly dispose of the used LiON
battery.
Consult your bio-med department or your
local municipality regarding location(s) for
safe disposal and proper disposal methods.
Never ship back to the mfg.
Warning
Figure 3.17a
Battery Terminal Connector Plug
Figure 3.17b
Battery Cover Screws
