Chapter 3: Tags, IDTAD, & TTS3-4
Attaching LT / WW Tags
Note: LT and WW (Wander Wearable) tags are
both used for resident care.
To attach LT tags:
1) With the male part of the snap pointing in
the same direction as the tag's Accutech
logo is facing, slide the plastic band
through the tag's slot. (Figure 3.6)
2) Adjust the band length to the nearest
accommodating hole for a comfortable
fit around the patient’s extremity.
Important: The band can not be adjusted
once it is secured.
3) Put the male part of the snap through
the selected hole on the inner side of the
band (Figure 3.7).
4) Fold over the female part of the Snap and
secure to the male part by squeezing until
they snap together.
5) Using scissors, carefully trim any excess
band material. (Figure 3.8)
6) Use an IDTAD to activate the tag.
Figure 3.6
LT Tag Band
Figure 3.7
LT Tag Band Adjustment
Figure 3.8
LT Tag with Band Secured and Trimmed
