1-9Chapter 1: The LC1400 System
Typical Layouts
• Single Door
• Double Door
• Hallway
• Single Elevator
• Double Elevator
• Triple Elevator
• Elevator Interior
• Single Door with Outer Windows
• Double Door with Outer Windows
• Sliding Glass Doors
Use the layouts on the following pages for
guidance on covering common monitored zone
layouts. Make changes as necessary to suit
environmental conditions and ensure proper
coverage.
