15. Appendix 7. Functional purpose of modules in Seagate
Arch F3 HDD
00 = SA defect list
01 = Drive Information File
02 = Performance Parameter File
03 = P-List
04 = SAP (Servo Adaptives Parameters)
05 = Manufacturing Information File
06 = RAP (Read Adaptive Parameters)
07 = CAP (Controller Adaptive Parameters)
08 = unknown purpose
09 = SMART config (filled with a pattern)
0A = SMART Frame
0B = unknown purpose, filled with a pattern
0C = Self Scan Log
0D = unknown purpose, filled with a pattern
0E = DIC (Data Integrity Check), HEAD 0
0F = DIC Dummy File
13 = disk registry (configuration settings, Security)
15 = offline surface self-test file (DOS)
16 = unknown purpose
17 = unknown purpose, filled with a pattern
19 = unknown purpose, some log
1A = unknown purpose, filled with a pattern
1B = unknown purpose, some log
1C = unknown purpose, filled with a pattern
1D = overlay 0
1E = overlay 1
1F = unknown purpose, filled with a pattern
22 = surface self-test file, head 0
23 = surface self-test file, head 1
24 = surface self-test file, head 2
25 = surface self-test file, head 3
26 = surface self-test file, head 4
27 = surface self-test file, head 5
28 = surface self-test file, head 6
29 = surface self-test file, head 7
2A = Saved Mode Pages – HDD settings
2B = RW operations, translator
2С = DIC (Data Integrity Check), HEAD 1, pattern
2D = DIC (Data Integrity Check), HEAD 2, pattern
2E = DIC (Data Integrity Check), HEAD 3, pattern
2F = DIC (Data Integrity Check), HEAD 4, pattern
30 = DIC (Data Integrity Check), HEAD 5, pattern
31 = DIC (Data Integrity Check), HEAD 6, pattern
32 = DIC (Data Integrity Check), HEAD 7, pattern
33 = FDE service file
34 = packed CONGEN structure descriptor
35 = SMART config (filled with a pattern)
