Acer 5336 - Replacing the LCD Assembly

108 Chapter 3
Replacing the LCD Assembly
1. Place the LCD assembly on the lower cover.
2. Replace four (4) screws to secure the LCD assembly.
3. Place the black antenna cable into the cable guides.
Step Size Quantity Screw Type
LCD Assembly M2.5*8 4
