Acer 5336 - Removing the Upper Cover

Chapter 3 61
Removing the Upper Cover
1. See “External Module Disassembly Process” on page 46.
2. Turn the computer over. Remove the ten (10) screws on the lower cover and four (4) screws from the battery
bay.
Step Size Quantity Screw Type
Lower Cover M2.5*8
(red callout)
10
M2*3
(green callout)
4
