Acer 5336 - LCD Module Disassembly Process

74 Chapter 3
Removing the Mainboard
1. See “Removing the Upper Cover” on page 61.
2. Disconnect the microphone cable from the mainboard.
3. Disconnect the LVDS cable from the mainboard.
4. Remove the LVDS cable and the DC-IN cable from the cable guide.
