Chapter 3 65
Removing the Speaker Module
1. See “Removing the Upper Cover” on page 61.
2. Locate the speaker module on the upper cover as shown.
3. Remove the speaker module cable from the cable guides.
4. Remove two (2) screws securing the speaker to the upper cover.
Step Size Quantity Screw Type
Upper Cover M2*3 2
To Next Page
