Acer 5336 - Removing the Mainboard

64 Chapter 3
7. Remove the eight (8) screws from the upper cover as shown.
8. Starting at the bottom right side of the cover, pry apart the upper and lower covers as shown. Work along the
front edge of the casing to the left as shown, then lift the upper cover clear of the lower cover.
Step Size Quantity Screw Type
Upper Cover M2.5*5 8
