Chapter 3 67
Removing the Power Board
NOTE: The power board may vary depending your model.
1. See “Removing the Upper Cover” on page 61.
2. Locate the power board on the upper cover as shown.
3. Remove one (1) screw from the power board.
4. Turn the upper cover over and remove the power board cable from the upper cover.
Step Size Quantity Screw Type
Power Board M2*3 1
To Next Page
