Chapter 3 87
Removing the Inverter Board
1. See “Removing the LCD Bezel” on page 85.
2. Remove the adhesive tape securing the inverter board cable to the LCD cover.
3. Remove one (1) screw from the inverter board.
4. Disconnect the inverter board cable going to the LCD panel.
Step Size Quantity Screw Type
Inverter Board M2.5*5 1
To Next Page
