Acer ASPIRE 5252 - Replacing the LCD Assembly

Chapter 3 113
Replacing the LCD Assembly
1. Place the LCD assembly on the lower cover.
2. Replace four (4) screws to secure the LCD assembly.
3. Place the black antenna cable into the cable guides.
Step Size Quantity Screw Type
LCD Assembly M2.5*8 4
Discrete UMA
