Acer ASPIRE 5252 - Replacing the HDD Module

Chapter 3 137
Replacing the HDD Module
1. Place the HDD in the HDD carrier.
2. Replace the four (4) screws (two each side) to secure the carrier.
3. Insert the HDD module, as indicated and lower it into place.
Step Size Quantity Screw Type
HDD Carrier M3*3 4
