Acer ASPIRE 5252 - Replacing the USB Board

Chapter 3 125
Replacing the USB Board
1. Place the USB board in the chassis.
NOTE: The location of the bluetooth module may vary depending on your model.
2. Secure the one (1) screw on the USB board.
3. Adhere the FFC to the lower cover.
Step Size Quantity Screw Type
USB Board M2*3 1
