Replacing the Lower Logic Door
1. Replace the lower logic door by first lining up the bottom edge and lowering the door into place.
2. Replace two (2) screws to secure the lower logic door.
Step Size Quantity Screw Type
Logic Lower Door M2.5*8 2
