Acer ASPIRE 5252 - Removing the ODD Module

Chapter 3 53
Removing the ODD Module
1. See “Removing the Battery Pack” on page 49.
2. Remove the one (1) screw securing the ODD module.
3. Pull the ODD module out from the chassis.
Step Size Quantity Screw Type
ODD Module M2.5*8 1
