Acer ASPIRE 5252 - Replacing the Battery

Chapter 3 147
Replacing the Battery
1. Slide and hold the battery release latch to the release position (1), insert the battery pack and press down (2).
2. Slide the battery lock in the direction shown to secure the battery in place.
1
2
