External Module Disassembly Process
External Modules Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
Lower Door M2.5*5 8 86.ARE07.003
ODD Module M2.5*5 1 86.ARE07.003
ODD Bracket M2*3 2 86.ARE07.002
HDD Carrier M3*3 2 86.A03V7.006
WLAN Module M2.5*4 2 86.EDM07.003
Disconnect power
and signal cables
from system
Remove
Battery
Turn off system
and peripherals
power
Remove
DIMMs
Remove
WLAN
Remove
HDD
Remove
ODD
Remove
Lower Door
Remove
RTC Battery
Remove
SD Dummy Card
To Next Page
