Chapter 3 63
Removing the TouchPad Bracket
IMPORTANT: The TouchPad is supplied as part of the Upper Cover. If the TouchPad is defective, replace the entire
Upper Cover.
1. See “Removing the Upper Cover” on page 60.
2. Remove the two screws securing the bracket to the Upper Cover.
3. Lift the bracket right side first and remove it from the Upper Cover as shown.
Step Size Quantity Screw Type
TouchPad
Bracket
M2.5*3 2
To Next Page
