Acer Extensa 5635 - Replacing the LCD Panel

Chapter 3 89
Replacing the LCD Panel
1. Place the LCD Panel adjacent to the LCD Cover and reconnect the Camera cable.
2. Turn the panel over and place it in the LCD Cover.
IMPORTANT: Ensure that the cables are not trapped under the panel.
3. Replace the four screws to secure the panel in place.
Step Size Quantity Screw Type
LCD Panel M2.5*5 4
