Acer Extensa 5635 - Removing the Mainboard

Chapter 3 73
Removing the Mainboard
1. See “Removing the Hinge Supports” on page 75.
2. Turn the computer over. Disconnect the power cable from the Mainboard as shown.
3. Remove the single screw securing the Mainboard to the Lower Cover.
Step Size Quantity Screw Type
Mainboard M2.5*5 1
