Acer Extensa 5635 - Replacing the LCD Brackets and FPC Cable

Chapter 3 87
Replacing the LCD Brackets and FPC Cable
1. Secure the brackets to the panel using six bracket screws (three each side).
2. Insert the LCD Cable into the panel connector
as shown.
3. Secure the connector by replacing the adhesive
strip as shown.
4. Replace the LCD cable as shown. Press down as indicated to secure the cable in place.
