Acer Extensa 5635 - Page 77

Chapter 3 67
6. Turn the Upper Cover over and remove the speaker cable from the cable clip as shown.
7. Remove the two screws (one each side) securing the Speaker Modules to the Upper Cover.
8. Remove the Speaker Modules from the Upper Cover as shown.
Step Size Quantity Screw Type
Speaker Module M2.5*3 2
