Acer Smart Display DA220HQL - Hdmi Timing

58
Camera
• Front camera
• 1.2-megapixel
• Fi
xed focus
Expansion
• microSD memory card slot (up to 32 GB)
Dimensions
Environment
Temperature
Operating: 0 °C to 35 °C
Non-operating: -20 °C to 60 °C
Humidity (non-condensing)
Operating: 20% to 80%
Non-operating: 20% to 80%
HDMI timing
Height 360 mm
Width 513 mm
Thickness 54 mm
Weight 4.8 kg
Item Resolution Refresh rate Horizontal
frequency
Pixel frequency
1 640 x 480 60 Hz 31.5 kHz 25.175 MHz
2 640 x 480 72 Hz 37.9 kHz 31.500 MHz
3 640 x 480 75 Hz 37.5 kHz 31.500 MHz
4 800 x 600 60 Hz 37.9 kHz 40.000 MHz
5 800 x 600 72 Hz 48.1 kHz 50.000 MHz
6 800 x 600 75 Hz 46.9 kHz 49.500 MHz
7 1024 x 768 60 Hz 48.4 kHz 65.000 MHz
8 1024 x 768 70 Hz 56.5 kHz 75.000 MHz
9 1024 x 768 75 Hz 60.0 kHz 78.750 MHz
10 1152 x 864 75 Hz 67.5 kHz 108.000 MHz
